• Detailed Product Introduction

• Downhole logging cables have to carry electrical signals while being handled, deployed and retrieved in a demanding well environment. A compact cable construction can be useful where available space is limited, while the outer protection needs to support the mechanical requirements of the operation. The GG1F46-4.0 1×0.56 uses a stranded soft copper conductor at its center. The conductor specification is 7 × 0.32 mm. Around the conductor is a 0.60 mm F46 insulation layer, followed by two 316L stainless steel tube layers. The inner stainless steel tube has a specified wall thickness of 0.30 mm, and the outer tube has a specified wall thickness of 0.40 mm. This layered construction forms the cable's compact armored body. The finished cable has a nominal diameter of 4.0 mm ± 0.05 mm and a weight in air of 79 kg/km. The specified operating temperature range is -50°C to +232°C, while the specified tensile strength is 7 kN. For electrical performance, the cable is specified for a 300 VDC withstand voltage. At 20°C, insulation resistance is ≥500 MΩ·km and DC resistance is ≤33 Ω/km. The specified capacitance is ≤0.16 μF/km.

Key Features

• Single-Core Construction
• A single stranded copper conductor forms the electrical core, providing a straightforward signal and power path within the armored structure.
• F46 Insulation
• The conductor is surrounded by an F46 insulation layer with a specified thickness of 0.60 mm.
• Dual 316L Stainless Steel Tube Layers
• The cable uses an inner 316L stainless steel tube layer and an outer 316L stainless steel tube layer. The specified wall thicknesses are 0.30 mm and 0.40 mm respectively.
• Compact 4.0 mm Diameter
• The finished cable has a specified outer diameter of 4.0 mm ± 0.05 mm, keeping the overall profile compact for downhole deployment.
• High-Temperature Specification
• The stated cable temperature range is -50°C to +232°C.
• 7 kN Tensile Strength
• The specified tensile strength is 7 kN, providing the mechanical load capacity stated in the product specification.

• Applications

1. Downhole logging
2. Wireline logging systems
3. Downhole instrumentation
4. Compact-diameter logging assemblies

FAQ

1. What is the GG1F46-4.0 1×0.56 cable?
2. It is a single-core logging cable using a stranded soft copper conductor, F46 insulation and two layers of 316L stainless steel tube protection.
3. What is the cable diameter?
4. The specified outer diameter is 4.0 mm ± 0.05 mm.
5. What is the conductor specification?
6. The conductor is 7 × 0.32 mm stranded soft copper wire.
7. What is the temperature range?
8. The specified temperature range is -50°C to +232°C.
9. What is the tensile strength?
10. The specified tensile strength is 7 kN.
11. How is the stainless steel tube structure built?
12. The cable has an inner 316L stainless steel tube with a 0.30 mm wall thickness and an outer 316L stainless steel tube with a 0.40 mm wall thickness.
13. What is the withstand voltage?
14. The specified withstand voltage is 300 VDC.
15. What is the insulation resistance?
16. At 20°C, the specified insulation resistance is ≥500 MΩ·km.
